| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | MACX MCR-EX-SL-2NAM-R-UP |
| Approvals | IECEx, ATEX, UL Listed, cUL Listed, EAC Ex, cULus Listed, Functional Safety, UL Listed, cUL Listed, EAC, cULus Listed, GL |
| Color | This product is transitioning from the current base color of green to gray. During the transition, the manufacturer will ship green product until depleted, followed by gray. The change is purely cosmetic in nature and does not impact the form, fit, function or technical ratings of the product. |
| Current Rating | 80 A |
| Input Type | Current, Voltage |
| Maximum Operating Temperature | 60 °C |
| Minimum Operating Temperature | -20 °C |
| Module Type | Isolation |
| Mounting Type | DIN Rail |
| Number of Channels | 2 |
| Output | Current |
| Output Type | Analog |
| Series | |
| Special Features | 3-Way Electrical Isolation, Line Fault Detection (LFD), can be Activated⁄Deactivated, Error Indicated by Red Flashing LED with De-Excitation of Output Relay, Relay Signal Output (PDT) |
| Standards | ATEX, CE Compliant, Canada, IECEx, UL, USA |
| Supply Voltage | 24 to 230 V ac⁄dc |
| Temperature Operating Range | -20 to 60 °C |
| Termination | Screw |
| Type | Amplifier |
| UPC Code | 4046356462532 |
Overview
Phoenix Contact MCR Series – MINI Analog Highly Compact Signal Conditioner:
Maximum signal quality with minimal space requirements – MINI Analog signal conditioners isolate, convert, filter, and amplify your analog signals – with a design width of just 6.2 mm.
The configurable MINI Analog modules are easy to set with DIP switches – without the need for any software. Alternatively, Phoenix Contact can make the settings based on your individual ordering information. For enhanced functionality and monitoring you can also configure the modules with the robust S-Port interface conveniently using a free-of-charge software interface. Here you can choose between three solutions:
1. Standalone ANALOG -CONF software
2. FDT/DTM software package
3. Standalone DTMs, allowing you to use your
existing FDT frame application
Features:
